150KW 188KVA 60HZ Cummins emergency generator genset set

  • CCFJ150YW (6CTA8.3-GM175)

  • Cummins

  • 8502120000

  • 150KW 188KVA

  • 60HZ

  • Emergency

  • Double starter ( Electric or Air/ Manual)

150KW 188KVA 60HZ Cummins emergency generator genset set

Generator model CCFJ150YW
Rated power 150KW
Standby power  165KW
Generator capacity 188KVA
Factor 0.8 lag
Frequency 60HZ
Voltage 440/260V
Current 271A
Phase / connection 3 phase 4 wire
Generator Weight 2600KG
Size  2890x1220x1750mm
Engine  Cummins 6CTA8.3-GM175
Rated power 175KW
Standby power  193KW
Bore*stroke 114x134 (mm)
Speed 1800RPM
Alternator  Marathon MP-H-150-4
Alternator  Sunvim SVH274
Excitation Brushless & self-excited
Insulation  H
Protection IP22/23
Starting model  Double starter
