ADVANCE HCT2000 marine gearbox transmission

Quantity:
Inquire Add to Basket

  • HCT2000

  • ADVANCE

  • 8483409000

  • ADVANCE

  • 600-1500RPM

  • 270KN

ADVANCE HCT2000 marine gearbox transmission

Speed ratio HP/RPM KW/RPM
5.185 5.494 5.943 6.583 7.012 7.483 8 2.01 1.48
8.57 1.93 1.42
8.843 1.82 1.34
9.428 1.67 1.23
10.05 1.65 1.21
11 1.36 1

Engine speed:600-1500RPM
Max 3000HP/1500RPM
LxWxH: 1284x1600x1835mm
Bell housing: without
Flywheel: according to engine
Net weight:5600KG
Control: electrical and pneumatic
Centre distance: 626mm
Rated propeller thrust: 270KN
