ADVANCE HCT400A marine gearbox transmission

Quantity:
Inquire Add to Basket

  • HCT400A

  • ADVANCE

  • 8483409000

  • ADVANCE

  • 1000-2100RPM

  • 82KN

ADVANCE HCT400A marine gearbox transmission

Speed ratio HP/RPM KW/RPM
6.09 6.49 6.93  0.45 0.33
7.42 0.42 0.31
7.95 0.39 0.29
8.40 0.36 0.26
9.00 9.47 0.33 0.24

Engine speed:1000-2100RPM
Max 945HP /2100RPM
LxWxH: 800×1052×1130mm
Net weight:1450KG
Bell housing: SAE 0 1
Flange: SAE 14,16,18
Control: mechanical or electrical remote control
Centre distance: 375mm
Rated propeller thrust: 82KN
