CCFJ100JW (WP6CD132E201)
Weichai Deutz
8502120000
100KW 125KVA
60HZ
Double circulate water cooling
| Genset Model | | CCFJ100JW |
| Engine model | | Weichai WP6CD132E201 |
| Alternator model | | Marathon MP-H-100-4 |
| Prime power | (KW/KVA) | 100KW/125KVA |
| Frequency | (HZ) | 60 |
| Rated speed | (RPM) | 1800 |
| Rated current | (A) | 181 |
| Rated voltage | (V) | 440/250V |
| Engine power | (KW/KVA) | 120KW/150KVA |
| Cylinder Nos. | | 6 |
| Bore x stroke | (mm) | 105*130 |
| Displacement | (L) | 6.75 |
| Fuel comsumption | (L/h) | 22.5 |
| Oil pan capacity | (L) | 18 |
| Governing method | | Mechanical or Electric |
| Voltage regulation mode | | Automatic |
| Phase and connection | | 3 phase-4wire |
| Weight | (KG) | 1400 |
| Size | (mm) | 2150*778*1385 |
| Certificate | | CCS+IMO Tier II |
| Genset Model | | CCFJ100JW |
| Engine model | | Weichai WP6CD132E201 |
| Alternator model | | Marathon MP-H-100-4 |
| Prime power | (KW/KVA) | 100KW/125KVA |
| Frequency | (HZ) | 60 |
| Rated speed | (RPM) | 1800 |
| Rated current | (A) | 181 |
| Rated voltage | (V) | 440/250V |
| Engine power | (KW/KVA) | 120KW/150KVA |
| Cylinder Nos. | | 6 |
| Bore x stroke | (mm) | 105*130 |
| Displacement | (L) | 6.75 |
| Fuel comsumption | (L/h) | 22.5 |
| Oil pan capacity | (L) | 18 |
| Governing method | | Mechanical or Electric |
| Voltage regulation mode | | Automatic |
| Phase and connection | | 3 phase-4wire |
| Weight | (KG) | 1400 |
| Size | (mm) | 2150*778*1385 |
| Certificate | | CCS+IMO Tier II |
