300KW 375KVA 60HZ Weichai marine diesel generator genset set (CCFJ300JW / WP13CD385E201)

  • CCFJ300JW (WP13CD385E201)

  • Weichai

  • 8502131000

  • 300KW 375KVA

  • 60HZ

  • Double circulate water cooling

300KW  375KVA  60HZ  Weichai marine diesel generator genset set (CCFJ300JW / WP13CD385E201)

Genset Model
Engine model
Weichai WP13CD385E201
Alternator model
Marathon MP-H-300-4
Prime power  (KW/KVA) 300KW/375KVA
Frequency (HZ) 60
Rated speed (RPM) 1800
Rated current (A) 541
Rated voltage (V) 440/250V
Engine power  (KW/KVA) 350KW/438KVA
Cylinder Nos.
Bore x stroke (mm) 126*165
Displacement  (L) 12.54
Fuel comsumption (L/h) 69.1
Oil pan capacity (L) 36
Governing method
Mechanical or Electric
Voltage regulation mode
Phase and connection
3 phase-4wire
Weight  (KG) 2466
Size (mm) 2664*1000*1532
Fishing, transport, passenger, law enforcement ship
