Quantity: | |
---|---|
CCFJ900JW / QSK38-DM
Cummins
8502131000
900KW 1125KVA
50HZ
Sea water exchanger cooling
Type of Gen-set | | Cummins marine diesel generator |
Generator model | | CCFJ900JW |
Rated Capacity | (KVA) | 1125KVA |
Rated Power | (KW) | 900KW |
Standby power | (KW) | 1000KW |
Diesel Engine | | Cummins QSK38-DM |
Alternator | | Marathon MX-H-1000-4 or Sunvim SVH454 |
Engine power | (KW) | 984KW |
Cooling Mode | | Heat Exchanger Cooling |
Rated Voltage | (V) | 400V |
Rated Current | (A) | 1624A |
Rated Frequency | (HZ) | 50HZ |
Power Factor(Lagging) | | 0.8 |
Phase & Connection | | Three Phases & Three Wires, Y Connection |
Rated Speed | (RPM) | 1500RPM |
Fuel Consumption | (g/kW.h) | ≤205 |
Starting Mode | | Electric Starting |
Weight of Gen-set | (KG) | 7000KG |
Overall Dimension | (mm) | 4100*1500*2500mm |
Certificate | | CCS,IMO,BV,etc |
Type of Gen-set | | Cummins marine diesel generator |
Generator model | | CCFJ900JW |
Rated Capacity | (KVA) | 1125KVA |
Rated Power | (KW) | 900KW |
Standby power | (KW) | 1000KW |
Diesel Engine | | Cummins QSK38-DM |
Alternator | | Marathon MX-H-1000-4 or Sunvim SVH454 |
Engine power | (KW) | 984KW |
Cooling Mode | | Heat Exchanger Cooling |
Rated Voltage | (V) | 400V |
Rated Current | (A) | 1624A |
Rated Frequency | (HZ) | 50HZ |
Power Factor(Lagging) | | 0.8 |
Phase & Connection | | Three Phases & Three Wires, Y Connection |
Rated Speed | (RPM) | 1500RPM |
Fuel Consumption | (g/kW.h) | ≤205 |
Starting Mode | | Electric Starting |
Weight of Gen-set | (KG) | 7000KG |
Overall Dimension | (mm) | 4100*1500*2500mm |
Certificate | | CCS,IMO,BV,etc |
