You are here: Home » Products » Marine emergency generator » Weichai marine emergency generator » 100KW 125KVA 50HZ Weichai marine emergency generator genset (CCFJ100YW)
Share to:

100KW 125KVA 50HZ Weichai marine emergency generator genset (CCFJ100YW)

Quantity:
  • CCFJ100YW
  • Weichai
  • 8502120000
  • 100KW 125KVA
  • 50HZ
  • Emergency
  • Close water cooling system
100KW 125KVA 50HZ Weichai marine emergency generator genset (CCFJ100YW)

Generator model CCFJ100YW
Rated power 100KW
Standby power  110KW
Generator capacity 125KVA
Factor 0.8 lag
Frequency 50HZ
Voltage 400/230V
Current 180A
Phase / connection 3 phase 4 wire
Generator Weight 1180KG
Size  2601x979x1569mm
Engine  Weichai WP6CD132E200
Rated power 120KW
Standby power  132KW
Bore*stroke 105x130 (mm)
Speed 1500RPM
Alternator  Marathon MP-H-100-4
Alternator  Sunvim SVH274
Excitation Brushless & self-excited
Insulation  H
Protection IP22/23
Governor Electric
Starting model  Double starter





Company profile

Shanghai Rekino Engine Equipment Co.,Ltd is specialized in marine diesel engine, marine gearbox, marine generator, andave produc propulsion systems. Overy the past several years, Rekino has provided Cummins marine diesel engine, Weichai marine diesel engine, Yuchai marine diesel engine, SDEC,etc,...
