Shanghai Rekino Engine Equipment Co.,Ltd
A professional supplier of marine propulsion system
- Product Name
- Product Keyword
- Product Model
- Product Summary
- Product Description
- Multi Field Search
幻灯片
 |
| Quantity: | |
|---|---|
CCFJ200YW
Weichai
8502120000
200KW 250KVA
60HZ
Emergency
Close water cooling system
| Generator model | CCFJ200YW |
| Rated power | 200KW |
| Standby power | 220KW |
| Generator capacity | 250KVA |
| Factor | 0.8 lag |
| Frequency | 60HZ |
| Voltage | 440/260V |
| Current | 361A |
| Phase / connection | 3 phase 4 wire |
| Generator Weight | 2059KG |
| Size | 2542x1000x1572mm |
| Engine | Weichai WP10CD264E201 |
| Rated power | 240KW |
| Standby power | 264KW |
| Bore*stroke | 126x130 (mm) |
| Speed | 1800RPM |
| Alternator | Marathon MP-H-200-4 |
| Alternator | Sunvim SVH274 |
| Excitation | Brushless & self-excited |
| Insulation | H |
| Protection | IP22/23 |
| Governor | Electric |
| Starting model | Double starter |
| Generator model | CCFJ200YW |
| Rated power | 200KW |
| Standby power | 220KW |
| Generator capacity | 250KVA |
| Factor | 0.8 lag |
| Frequency | 60HZ |
| Voltage | 440/260V |
| Current | 361A |
| Phase / connection | 3 phase 4 wire |
| Generator Weight | 2059KG |
| Size | 2542x1000x1572mm |
| Engine | Weichai WP10CD264E201 |
| Rated power | 240KW |
| Standby power | 264KW |
| Bore*stroke | 126x130 (mm) |
| Speed | 1800RPM |
| Alternator | Marathon MP-H-200-4 |
| Alternator | Sunvim SVH274 |
| Excitation | Brushless & self-excited |
| Insulation | H |
| Protection | IP22/23 |
| Governor | Electric |
| Starting model | Double starter |
