| Quantity: | |
|---|---|
CCFJ150YW
Weichai
8502120000
150KW 188KVA
50HZ
Emergency
Close water cooling system
| Generator model | CCFJ150YW |
| Rated power | 150KW |
| Standby power | 165KW |
| Generator capacity | 188KVA |
| Factor | 0.8 lag |
| Frequency | 50HZ |
| Voltage | 400/230V |
| Current | 271A |
| Phase / connection | 3 phase 4 wire |
| Generator Weight | 2059KG |
| Size | 2375x1000x1572mm |
| Engine | Weichai WP10CD200E200 |
| Rated power | 182KW |
| Standby power | 200KW |
| Bore*stroke | 126x130 (mm) |
| Speed | 1500RPM |
| Alternator | Marathon MP-H-150-4 |
| Alternator | Sunvim SVH274 |
| Excitation | Brushless & self-excited |
| Insulation | H |
| Protection | IP22/23 |
| Governor | Electric |
| Starting model | Double starter |
