120KW 150KVA 60HZ Weichai marine emergency generator genset (CCFJ120YW)

Quantity:
  • CCFJ120YW

  • Weichai

  • 8502120000

  • 120KW 150KVA

  • 60HZ

  • Emergency

  • Close water cooling system

120KW 150KVA 60HZ Weichai marine emergency generator genset (CCFJ120YW)

Generator model CCFJ120YW
Rated power 120KW
Standby power  132KW
Generator capacity 150KVA
Factor 0.8 lag
Frequency 60HZ
Voltage 440/260V
Current 217A
Phase / connection 3 phase 4 wire
Generator Weight 1500KG
Size  2540x982x1565mm
Engine  Weichai  WP6CD158E201
Rated power 144KW
Standby power  158KW
Bore*stroke 105x130 (mm)
Speed 1800RPM
Alternator  Marathon MP-H-120-4
Alternator  Sunvim SVH274
Excitation Brushless & self-excited
Insulation  H
Protection IP22/23
Governor Electric
Starting model  Double starter
