ADVANCE GCH/GCHT/GCHE Marine gearbox transmission

Share to:

ADVANCE GCH/GCHT/GCHE Marine gearbox transmission

Quantity:



Inquire Add to Basket

Model:
GCH/GCHT/GCHE
Brand:
ADVANCE
Code:
8483409000
Type :
GCH/GCHT/GCHE
Speed range :
200-1800RPM
thrust propeller :
100-1200KN

Product Description

Model	Input Speed	Reduction Ratio	Trans. Capacity	Rated Thrust	Net Weight
	(r/min)	(i)	(kW/r·min-1)	(kN)	(kg)
GCH320	400-1800	1.9688	0.537	100	320
		2.5185
		2.9583
		3.5238
		4
GCHT5	400-1800	4.5	0.537	120	445
		5
		5.55
		5.947
GCHE5	400-1800	6.5-8	0.537	170	570
GCH350	400-1800	2	0.684	113	350
		2.5566
		3
		3.5714
		4.0526
GCHT6	400-1800	4.5	0.684	140	480
		5
		5.55
		5.947
GCHE6	400-1800	6.5-8	0.684	200	615
GCH390	400-1800	2.0323	0.919	140	390
		2.4815
		2.9167
		3.4762
		3.9474
GCHT9	400-1800	4.5	0.919	220	545
		5
		5.55
		5.947
GCHE9	400-1800	6.5-8	0.919	270	700
GCH410	400-1600	2	1.169	175	410
		2.5357
		2.96
		3.5
		3.95
GCHT11	400-1600	4.52	1.169	220	570
		5.043
		5.52
		5.95
GCHE11	400-1600	6.5-8	1.169	270	735
GCH450	400-1600	1.973	1.573	220	455
		2.5484
		2.9286
		3.5833
		4
GCHT15	400-1600	4.464	1.573	270	630
		5.08
		5.458
		5.955
GCHE15	400-1600	6.5-8	1.573	300	810
GCH490	400-1400	2.0323	2.051	270	490
		2.4815
		3.087
		3.4762
		3.9474
GCHE20	400-1400	6.5-8	2.051	350	875
GCH540	400-1200	1.9714	2.647	284	540
		2.4667
		3
		3.5217
		3.9524
GCHT26	400-1200	4.577	2.647	350	750
		5.042
		5.59
		5.952
GCHE26	400-1200	6.5-8	2.647	400	960
GCH590	400-1200	1.9714	3.448	360	590
		2.4667
		3
		3.5217
		3.9524
GCHT33	400-1200	4.542	3.448	540	820
		5.045
		5.6
		5.947
GCHE33	400-1200	6.5-8	3.448	550	1055
GCH660	400-1200	2	4.625	540	668
		2.536
		2.96
		3.5
		3.95
GCH700	400-1050	2~4	6.86	350	700
GCHT44	400-1200	4.52	4.625	700	924
		5
		5.5714
		5.96
GCHE44	400-1200	6.5-8	4.625	800	1185
GCH750	300-900	1.9714	6.99	700	750
		2.4667
		3
		3.5217
		3.9524
GCH850	300-800	1.9714	9.6	800	855
		2.4667
		3
		3.5217
		3.9524
GCH950	200-650	2	14	1200	965
		2.536
		2.96
		3.5
		3.95
GCH1000	300-900	2月4日	6.99	450	1000
