FADA T300/2 Marine gearbox transmission

Quantity:
Inquire Add to Basket

  • T300/2

  • FADA

  • 8483409000

  • T300/2

  • 1000-2100RPM

  • 82KN

FADA  T300/2  Marine gearbox transmission

Model Nominal ratio Actual ratio Transfer Capacity (KW/RPM) Transfer Capacity (HP/RPM)
T300/2 7.8 7.8086 0.243 0.330
8.3 7.3409 0.221 0.301
9.0 8.9263 0.213 0.290
9.5 9.5734 0.200 0.270
10.0 10.1053 0.200 0.270
10.5 10.6371 0.200 0.270



Rated speed : 750-2300RPM
Bell housing: SAE0 1
Center distance: 355mm
Push power:70 KN
Net weight: 1120 KG
Control: Mechanical, Electrical
