Fenjin FJ400 Marine gearbox transmission

Quantity:
Inquire Add to Basket

  • FJ400

  • FENJIN

  • 8483409000

  • 1000-1800RPM

  • 82KN

Fenjin  FJ400 Marine gearbox transmission


Model Nominal Ratio Real Ratio Rate (KW/RPM) Rate (HP/RPM)
FJ400 1.5 1.50 0.331 0.450
1.8 1.77 0.331 0.450
2.0 2.04 0.331 0.450
2.5 2.50 0.331 0.450
2,9 2.86 0.331 0.450
3.0 3.00 0.331 0.450
3.5 3.42 0.331 0.450
4.0 4.06 0.279 0.380
4.5 4.61 0.190 0.258
5.0 4.94 0.190 0.258


Speed range: 1000-1800 RPM
Rated thrust propeller: 82KN
Center Distance 264mm
Direction of rotation of the output shaft: Contrary
Bell housing: SAE 0 1
Control: Mechanical, electrical, pneumatic,
Flywheel: SAE 14 11.5
Size: 641x950x890mm
Net weight: 820KG
